IP68 Waterproof Foldable Solar Panel Portable 450W

Name: IP68 Waterproof Foldable Solar Panel Portable 450W
Brand: Finergy Solar Tech
Price: 0.22 USD

China IP68 Waterproof Foldable Solar Panel Portable 450W wholesale

Brand Name : Finergy Solar Tech

Model Number : 450W/9BB mono PERC half cell module

Certification : CE, IEC61215, IEC61730, TUV, CQC

Place of Origin : WUXI, CHINA

MOQ : 128PCS

Price : 0.22~0.24 USD per watt

Payment Terms : T/T, L/C at sight, Western Union

Supply Ability : 10MW per month

Delivery Time : 10 work days

Packaging Details : 31PCS/pallet, 64PCS/stack

Solar Cell : 9BB mono PERC solar cells from LONGi and URECO

Pattern : 144 half cells assembly with split junction box and connectors

Advantage : High efficiency with excellent performance in low light environment

Selling Point : Stable power output even half panel is shaded

Application : Residential, commercial and industrial solar power system

Warranty : 12 years workmanship and 30 years power damping guarantee

Contact Now

FSM440~FSM450M72H (440W/445W/450W) MONO PERC 144 Half Cells PV Module

Electrical Characteristics under STC (Irradiance 1000W/m², Cell Temperature 25℃, Air Mass 1.5)

Module Type	FSM440M72H	FSM445M72H	FSM450M72H
Maximum Power-Pmax (Wp)	440	445	450
Voltage at Maximum Power-Vmp (V)	41.0	41.2	41.4
Current at Maximum Power-Imp (A)	10.74	10.81	10.88
Open Circuit Voltage-Voc (V)	49.6	49.8	50.0
Short Circuit Voltage-Isc (A)	11.33	11.40	11.47
Module Efficiency-ηm (%)	20.2%	20.5%	20.7%
Operating Temperature	-40℃ to +85℃
Maximum System Voltage	1000V/1500V DC (IEC)
Power Tolerance	0~+4.99W
Temperature Coefficients of Pmax	-0.350%/℃
Temperature Coefficients of Voc	-0.289%/℃
Temperature Coefficients of Isc	0.048%/℃

Mechanical Characteristics

Cell Type	9BB M6 MONO PERC 166×83mm
No. of Cells	144 (2×72)
Dimension	2094×1038×35mm
Weight	24 Kg
Junction Box	IP68, 3*22A diodes
Output Cables	4.0mm², 500mm Length (Optional)
Connectors	MC4 compatible
Packing	31PCS/Pallet, 704PCS/40’HC

Product Features

Gallium doped Mono Half Cell adopts PERC technology to guarantee higher output power and higher module efficiency (up to 20.7%).
9 busbar pattern together with half cell design to ensure 5~10W higher power generation.
Mono PERC Half Cell PV module offers better temperature-dependent performance, less shading effect on the energy generation, lower risk of hot spot.
Excellent Anti-PID performance guarantee limited power degradation for mass production.
IP68 rated split junction box with diodes to protect the full PV system safety, MC4 compatible connectors for easy installation.
Advanced glass and cell surface textured design ensure excellent performance in low-light environments (e.g. early morning, dusk and cloud, etc).
Three channels of EL automatic detections and power test before packing.
MES system applied together with production line to ensure products information searchable and traceable.
12 years product material & craft warranty and 30 years linear power damping warranty based on around 0.55% annual power degradation.

Who's FINERGY?

FINERGY Solar Tech headquartered in Wuxi, PR China, is a spin-off of Delin Group. FINERGY launched 3 international ISO certified workshops in the industrial park which produce both mono and poly crystalline solar panels. With the development of emerging market, we enlarged the capacity of solar panels production to 800MW per year.

FINERGY workshops were covered by 3.5MW solar power roof system. It continues providing the power consumption of automatic equipment and production lines for solar panels manufacturing.

FINERGY delivers hundreds MW of proven solar performance to residential, commercial and utility scale power plant customers per year, which can get more benefits from our collaborations.

FINERGY has set up sales network in Asia, South America and Europe. The solar panels produced from FINERGY have been exported to more than 40 countries all over the world.

Semi-finished Product At Site

IP68 Waterproof Foldable Solar Panel Portable 450W

Warehouse for FINERGY Solar Panels Storage

IP68 Waterproof Foldable Solar Panel Portable 450W
