24 Volt Poly Solar Panel 275W-285W

Name: 24 Volt Poly Solar Panel 275W285W
Brand: Finergy Tech
Price: 0.195 USD

China 24 Volt Poly Solar Panel 275W-285W wholesale

Brand Name : Finergy Tech

Model Number : 275W~285W Poly

Certification : CE, IEC61215, IEC61730, TUV, CEC

Place of Origin : CHINA

MOQ : 100PCS

Price : 0.195~0.20 USD per watt

Payment Terms : T/T, L/C

Supply Ability : 10MW per month

Delivery Time : 10 work days

Packaging Details : Standard Plywood Packing

Cell Source : JA, GCL, Yingli Solar, Suntech

Technology : Black silicon wafer with 5BB

Features : Most economical price with standard 60 cell design

Application : Residential, commercial and industrial solar systems

Special Service : OEM & ODM are acceptable

Warranty : 12 years + 25 years

Contact Now

FSM275~FSM285P660 (275W/280W/285W) Standard Poly-Crystalline PV Module

KEY FEATURES

5 Busbar Poly-Crystalline Solar Cell adopts new technology to guarantee higher output power and higher module efficiency.
Excellent Anti-PID performance guarantee limited power degradation for mass production.
Advanced glass and cell surface textured design ensure excellent performance in low-light environment.
Certified to withstand: wind load (2400 Pa) and snow load (5400Pa)
High salt mist and ammonia resistance certified by TUV.
Separate trackable barcode on each product for quality tracing.
Three times online EL inspections and power test before packing.
12 years product warranty and 25 years linear power warranty.

Electrical Characteristics under STC

Module Type	FSM275P660	FSM280P660	FSM285P660
Maximum Power-Pmax (Wp)	275	280	285
Voltage at Maximum Power-Vmp (V)	31.5	31.8	32.2
Current at Maximum Power-Imp (A)	8.73	8.81	8.86
Open Circuit Voltage-Voc (V)	38.3	38.5	38.9
Short Circuit Voltage-Isc (A)	9.17	9.23	9.28
Module Efficiency-ηm (%)	16.9%	17.2%	17.5%
Operating Temperature	-40℃ to +85℃
Maximum System Voltage	1000V/1500V DC (IEC)
Power Tolerance	0~+4.99W
Temperature Coefficients of Pmax	-0.40%/℃
Temperature Coefficients of Voc	-0.31%/℃
Temperature Coefficients of Isc	0.04%/℃

Mechanical Characteristics

Cell Type	Black Silicon Poly 157×157mm
No. of Cells	60 (6×10)
Dimension	1640×992×35mm
Weight	19 Kg
Junction Box	IP68, 3*20A diodes
Output Cables	4.0mm², 1100mm Length (Optional)
Connectors	MC4 compatible
Packing	31PCS/Pallet, 924PCS/40’HC

Advantage of Finergy Solar Tech

Cost Control

Finergy is in-depth study of intelligent manufacturing. We combined international advanced automation facilities and production lines together with ERP, MES, WMS and CRM information systems. We will actively explore and practice the integration of the two to build a smart factory. In the processes of promotion, we will improve the process capacity, reduce the number of products in process, improve the production efficiency; improve the rate of good products, reduce the quality cost; save the labor cost, eliminate the waste and reduce the comprehensive cost.

Quality Control

Quality is the life of Finergy. The company established a perfect quality control system and implements the whole process quality control of raw materials, production, inspection, warehousing, delivery and etc. Through advanced automatic equipment and production line, it’s able to eliminate human defects and improve products quality. Through digital information systems, we can achieve products quality traceability, provide customers with efficient and quick after-sales service to protect the benefits of customers.

Automatic Production Processes

Sucessful Cases
